Transonic 1.3

€5.999,00
Please note that price can vary per country
Size Guide
Size
Color

This product is unavailable

Transonic flight pushes the envelope of the speed of sound. Aboard Fuji’s flagship aero road bike, take flight as revolutionary linear frame design meets engineering and integration. Effortlessly accelerate towards the upper reaches of speed and performance a bike can offer.

Learn More
Technical Specifications

  • Sizes

    XXS (46cm), XS (49cm), S (52cm), M (54cm), L (56cm), XL (58cm), XXL (61cm)

    Color(s)

    Matte Carbon / Oil Slick

    Frame

    C15 ultra high-modulus schedule process. High compaction molding. Aero optimized integration. PF30 BB, 142x12 thru-axle.

    Fork

    C15 ultra high-modulus schedule process. High compaction molding. Aero optimized integration. 100x12mm thru-axle

    Crankset

    Shimano Ultegra 8100 12spd 52-36

    Bottom Bracket

    Praxis PF30 for Shimano

    Front Derailleur

    Shimano Ultegra Di2 8150 2x12

    Rear Derailleur

    Shimano Ultegra Di2 8150 12spd

    Shifters

    Shimano Ultegra Di2 8150 2x12

    Cassette

    Shimano Ultegra 8100 12spd 11-34

  • Chain

    Shimano Ultegra 12spd

    Wheelset

    Vision Tech TC55, carbon, tubeless ready

    Tires

    Vittoria Corsa, G2.0, 700 x 28c

    Brakeset

    Shimano 8170

    Brake Levers

    Shimano Ultegra Di2 8150 2x12

    Headset

    FSA, 1 1/4" upper - 1 1/2" lower, integrated

    Handlebar

    Oval Concepts 990 Aero carbon, 31.8mm clamp, 125mm drop / 75mm reach

    Stem

    Oval Concepts 790 Aero, 3D-forged, -17°, integrated computer mount

    Tape

    Selle Italia SG Tape

    Saddle

    Selle Italia Model X

    Seatpost

    Transonic Aero Carbon

*Specifications are subject to change without notice
Geometry
Size XXS XS S M L XL XXL
A Seat Tube Center To Top 440 457 484 503 520 538 567
B Seat Tube Effective 460 490 520 540 560 580 610
C Top Tube Effective 500 515 537 552 565 581 600
D Head Tube Length 93 109 129 145 166 183 203
E Seat Tube Angle 74.75° 74.3° 74.2° 74.2° 73.5° 73.5° 73°
G Headtube Angle 70.6 71 72 72.7 73 73 73
H Chainstay Length 410 410 410 410 410 410 410
I Wheelbase 971.3 982 988 989 999 1016 1030
J Bottom Bracket Drop 73 70 70 68 68 66 66
K Fork Offset 52 52 52 43 43 43 43
L Trail 63.72 61.21 54.98 60.08 58.22 58.22 58.22
M Stack 487 500 523 541 562 576.5 596
N Reach 367 374 382 392 399 410 418
O Standover 730 747 772 788 806 824 846
Stem 70 90 90 100 110 120 120
Handlebar Width 380 400 400 420 420 440 440
Crank 165 170 170 172.5 172.5 175 175
Wheel Size 700 700 700 700 700 700 700
Seat Post Diameter N/A N/A N/A N/A N/A N/A N/A
