Jari Carbon CX

€3.499,00
Please note that price can vary per country
Size Guide
Size
Color

This product is unavailable

Performance, utility and versatility the Jari delivers them all. Designed to take on gravel races, light touring, bikepacking or pretty much whatever you can throw at it. The Jari is a chameleon that seamlessly changes into whatever you need it to be. Long, slack geometry provides a stable and confidence-inspiring ride no matter what the terrain, allowing you to comfortably grind gravel or tackle tarmac all day long. Remember the journey is the best part of the trip and the Jari is the perfect traveling partner.
Learn More
Technical Specifications

  • Sizes

    XS (49cm), S (52cm), M (54cm), L (56cm), XL (58cm), XXL (61cm)

    Color(s)

    Eggplant

    Frame

    C15 ultra high-modulus schedule process. High compaction molding. Micro-suspension rear triangle. English threaded BB, 142x12 thru-axle.

    Fork

    C15 ultra high-modulus schedule process, tapered steerer, 100x12mm thru-axle

    Crankset

    SRAM RIVAL 1X12 40T DUB

    Bottom Bracket

    SRAM DUB English threaded

    Rear Derailleur

    SRAM Rival AXS 1x12

    Shifters

    SRAM Rival AXS Hydraulic

    Cassette

    SRAM XG1250 10-36 12spd

    Chain

    SRAM Rival 12spd

  • Wheelset

    Oval Concepts 524 Disc, 24/28H, 21mm internal width

    Tires

    Vittoria Mezcal, G2.0, 700 x 35c

    Tubes

    700 x 35 presta

    Brakeset

    SRAM Hydraulic FM, 160mm rotor

    Brake Levers

    SRAM Rival AXS Hydraulic

    Headset

    FSA, 1 1/8” upper - 1 1/2” lower, integrated

    Handlebar

    Oval Concepts 310 Ergo, 6061 alloy, 31.8mm clamp, 133mm drop, 4Β° sweep

    Stem

    Oval Concepts 313, 3D-forged 6061, +/-6Β°

    Tape

    Selle Italia Smootape Corsa

    Saddle

    Selle Italia X-LR Air Cross Light

    Seatpost

    Oval Concepts 300, alloy, 27.2mm

*Specifications are subject to change without notice
Geometry
Size XS S M L XL XXL
A Seat Tube Center To Top 490 520 540 560 580 610
C Top Tube Effective 525 535 545 560 575 590
D Head Tube Length 120 140 150 170 190 210
E Seat Tube Angle 74,5Β° 74Β° 73Β° 73Β° 72.5Β° 72.5Β°
G Headtube Angle 70.5Β° 71Β° 71.5Β° 72Β° 72Β° 72Β°
H Chainstay Length 435 435 435 435 435 435
I Wheelbase 1020 1022 1016 1027 1037 1058
J Bottom Bracket Drop 69 67 67 67 65 65
K Fork Offset 48 48 48 48 48 48
L Trail 73 70 67 64 64 64
M Stack 541 560 572 592 609 628
N Reach 375 375 370 379 383 397
O Standover 767 790 804 824 841 865
Stem 80 90 90 100 110 110
Handlebar Width 380 400 420 420 440 460
Crank 165 170 172.5 172.5 172.5 175
Wheel Size 700 700 700 700 700 700
Seat Post Diameter 27.2 27.2 27.2 27.2 27.2 27.2
