Known for versatility, the Absolute's geometry strikes a balance between speed and comfort, making it ideal for the fitness-minded rider, or the urbanite looking to ride to work or run errands.
S (15"), M (17"), L (19"), XL (21"), XXL (23")
Black, Cool Gray
Fuji A2-SL custom butted alloy
Fuji Hi-Ten steel
Prowheel, 48/38/28T
Sealed cartridge bearing
Resin platform
Shimano Tourney OR microSHIFT
Shimano Tourney OR microSHIFT RD-M26L
Shimano Tourney, EZ Fire OR microSHIFT TS-38, 3 x 7-speed
Shimano Tourney OR Tri-Diamond, 14-34T freewheel
KMC HV500
Weinmann double wall rims 32h
Kenda Tendril, 700 x 38c OR Goodyear Transit Tour 700 x 40c
Tektro alloy linear pull
Shimano Tourney OR Tektro RS360A
1-1/8" semi-integrated
Alloy, 20mm rise, 6° backsweep
Alloy, 25°, 25.4mm
Velo comfort
Fuji comfort sport
Alloy, 27.2mm
12.28 kg / 27.00 lbs
| Size | S | M | L | XL | XXL | |
|---|---|---|---|---|---|---|
| Bike Size | 15" | 17" | 19" | 21" | 23" | |
| A | Seat Tube, Center To Top | 381 | 432 | 483 | 533 | 584 |
| C | Top Tube, Effective | 533 | 549 | 575 | 600 | 625 |
| D | Head Tube Length | 120 | 145 | 170 | 190 | 220 |
| E | Seat Tube Angle | 75° | 74° | 73° | 73° | 73° |
| G | Head Tube Angle | 69° | 70° | 71° | 71° | 71° |
| H | Chainstay Length | 440 | 440 | 440 | 440 | 440 |
| I | Wheelbase | 1055 | 1055 | 1060 | 1060 | 1112 |
| J | Bottom Bracket Drop | 60 | 60 | 60 | 60 | 60 |
| K | Fork Offset | 45 | 45 | 45 | 45 | 45 |
| M | Stack | 528 | 555 | 583 | 601 | 630 |
| N | Reach | 392 | 390 | 395 | 416 | 432 |
| O | Standover | 728 | 765 | 802 | 835 | 873 |
| Stem | 80 | 80 | 100 | 100 | 100 | |
| Handlebar Width | 620 | 620 | 680 | 680 | 680 | |
| Crank | 170 | 170 | 175 | 175 | 175 | |
| Wheel Size | 700c | 700c | 700c | 700c | 700c | |
| Seat Post Diameter | 27.2 | 27.2 | 27.2 | 27.2 | 27.2 |
