Transonic 2.3

€3.299,00
Please note that price can vary per country
Size Guide
Size
Color

This product is unavailable

Transonic flight pushes the envelope of the speed of sound. Aboard Fuji’s flagship aero road bike, take flight as revolutionary linear frame design meets engineering and integration. Effortlessly accelerate towards the upper reaches of speed and performance a bike can offer.

Learn More
Technical Specifications

  • Sizes

    XXS (46cm), XS (49cm), S (52cm), M (54cm), L (56cm), XL (58cm), XXL (61cm)

    Color(s)

    Stone Blue

    Frame

    C10 high-modulus schedule process. High compaction molding. Aero optimized integration. PF30 BB, 142x12 thru-axle.

    Fork

    C10 high-modulus schedule process. High compaction molding. Aero optimized integration. 100x12mm thru-axle

    Crankset

    Shimano 105 or FSA Gossamer Pro, 50/34T

    Bottom Bracket

    Praxis PF30 M24

    Front Derailleur

    Shimano 105

    Rear Derailleur

    Shimano 105

    Shifters

    Shimano 105 Dual Control, 2 x 11-speed

    Cassette

    Shimano 105, 11-30T

    Chain

    KMC X11

  • Wheelset

    Oval Concepts 524 Disc, 24/28H

    Tires

    Vittoria Zaffiro Pro V, G2.0, 700 x 28c

    Tubes

    700 x 28 presta

    Brakeset

    Shimano 105, hydraulic disc, 160mm rotor

    Brake Levers

    Shimano 105, hydraulic disc

    Headset

    FSA, 1 1/4" upper - 1 1/2" lower, integrated

    Handlebar

    Oval Concepts 310 Ergo, 6061 alloy, 31.8mm clamp, 133mm drop, 4° sweep

    Stem

    Oval Concepts 313, 3D-forged 6061, +/-6°

    Tape

    Selle Italia Smootape Corsa

    Saddle

    Selle Italia X Base

    Seatpost

    Transonic Aero Carbon

*Specifications are subject to change without notice
Geometry
Size XXS XS S M L XL XXL
A Seat Tube Center To Top 440 457 484 503 520 538 567
B Seat Tube Effective 460 490 520 540 560 580 610
C Top Tube Effective 500 515 537 552 565 581 600
D Head Tube Length 93 109 129 145 166 183 203
E Seat Tube Angle 74.75° 74.3° 74.2° 74.2° 73.5° 73.5° 73°
G Headtube Angle 70.6 71 72 72.7 73 73 73
H Chainstay Length 410 410 410 410 410 410 410
I Wheelbase 971.3 982 988 989 999 1016 1030
J Bottom Bracket Drop 73 70 70 68 68 66 66
K Fork Offset 52 52 52 43 43 43 43
L Trail 63.72 61.21 54.98 60.08 58.22 58.22 58.22
M Stack 487 500 523 541 562 576.5 596
N Reach 367 374 382 392 399 410 418
O Standover 730 747 772 788 806 824 846
Stem 70 90 90 100 110 120 120
Handlebar Width 380 400 400 420 420 440 440
Crank 165 170 170 172.5 172.5 175 175
Wheel Size 700 700 700 700 700 700 700
Seat Post Diameter N/A N/A N/A N/A N/A N/A N/A
